D12.01 Kolon Tutucu Flans / Clamping Flange

Malzeme - Material 1040
a b c d e f g h j Siparis Kodu Order Code PSA - Mabec Code RENAULT - Mabec Code
25 28 2.7 10 45 31 6.6 11 7 D12.01_ 25 Z000 248 844 P483 784 100
32 37 4.2 10 56 36 6.6 11 7 D12.01_ 32 P446 932 711 P483 784 600
40 45 4.2 12 70 50 6.6 11 7 D12.01_ 40 P446932 701 P483 795 100
50 55 4.2 14 80 55 9 16 9 D12.01_ 50 P446 932 702 P483 795 401
63 70 6.2 18 100 70 11 19 11 D12.01_ 63 P446 932 703 P483 795 801
80 87 6.2 20 110 80 13 22 14 D12.01_ 80 P446 932 704 P483 796 001
100 107 6.2 20 140 100 13 22 14 D12.01_100 P483 796 401
