D41 Boynuz Pimi Yatağı / Retainer
Malzeme - Material 1.7131 (16MnCr5)
Sertlik - Hardness 61 - 63 HRC
Isıl İşlem - Heat Treatment Sementasyon (Case Hardened)
| d1 | d2 | d3 | M | s | s1 | t | I1 | I3 | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|---|---|---|---|
| 32 | 12 | 16 | M6 | 36 | 9.9 | 12 | 7 | 10 | D41_12 |
| 36 | 14 | 18 | M8 | 36 | 8.2 | 16 | 7 | 12 | D41_14 |
| 40 | 16 | 20 | M8 | 46 | 8.2 | 16 | 8.5 | 13.5 | D41_16 |
| 45 | 20 | 25 | M8 | 46 | 8.2 | 16 | 8.5 | 15 | D41_20 |
| 50 | 25 | 29 | M8 | 56 | 8.2 | 16 | 10 | 16 | D41_25 |
| 63 | 30 | 34 | M10 | 66 | 8.2 | 20 | 12 | 21 | D41_30 |
