D50.01.04 Kare Kilitleme - Square Interlock
Malzeme - Material 1.2343
Sertlik - Hardness 52 - 54 HRC
| h | e | e1 | c | M | I1 | I | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|---|---|
| 25 | 17.5 | 8 | 5 | M5 | 36 | 50 | D50.01.04_050 |
| 30 | 22 | 10 | 5 | M6 | 60 | 100 | D50.01.04_100 |
| 40 | 25 | 13 | 5 | M6 | 100 | 150 | D50.01.04_150 |
