D51.02 Merkezleme Pimi / Locating Pin
Malzeme - Material Çelik - Steel 16MnCr5
Sertlik - Hardness 58 - 62 HRC
| d1 | M | r | I1 | I2 | I3 | Siparis Kodu / Order Code | VW/AUDI CODE |
|---|---|---|---|---|---|---|---|
| 22 | M8 | 15 | 45 | 16 | 35 | D51.02_2245 | 39V1205/1 |
| 22 | M8 | 15 | 55 | 16 | 45 | D51.02_2255 | 39V1205/2 |
| 32 | M10 | 20 | 50 | 20 | 35 | D51.02_3250 | |
| 40 | M10 | 25 | 55 | 20 | 35 | D51.02_4055 | 39V1205/3 |
| 40 | M10 | 25 | 65 | 20 | 45 | D51.02_4065 | 39V1205/4 |
| 40 | M10 | 25 | 85 | 20 | 65 | D51.02_4085 | 39V1205/5 |
| 50 | M10 | 25 | 55 | 20 | 35 | D51.02_5055 |
