D70.01 Düküm Blok - Guide Bearing
Malzeme - Material GG25
a | b | d | d1 | e1 | e2 | h | h1 | M | Sipariş Kodu | Order Code |
---|---|---|---|---|---|---|---|---|---|
130 | 80 | 40 | 10 | 95 | 45 | 77 | 30 | 12 | D70.01_40 |
160 | 96 | 50 | 10 | 118 | 55 | 95 | 35 | 14 | D70.01_50 |
180 | 110 | 63 | 12 | 132 | 62 | 120 | 35 | 16 | D70.01_63 |
215 | 130 | 80 | 14 | 160 | 75 | 120 | 40 | 20 | D70.01_80 |
