D80.16 Çelik Sürtünme Plakası / Sliding Pads

Malzeme - Material 1.7131 (16MnCr5)
Sertlik - Hardness 62 ± 2 HRC
w w1 w2 w3 M I1 I2 Form I Sipariş Kodu | Order Code VW/AUDI - 39D863 FORD - WDX 1365
50 25 M8x25 25 30 80 D80.16_ 50 80 62 01050100-X
50 25 M12x25 25 50 100 D80.16_ 50100 63 01050125-X
50 25 M12x25 25 75 125 D80.16_ 50125 64 01050160-X
50 25 M12x25 25 110 160 D80.16_ 50160 65 01050200-X
50 25 M12x25 25 150 200 D80.16_ 50200 66
80 40 M12x25 25 30 80 D80.16_ 80 80 72 01080100-X
80 40 M12x25 25 50 100 D80.16_ 80100 73 01080125-X
80 40 M12x25 25 75 125 D80.16_ 80125 74 01080160-X
80 40 M12x25 25 110 160 D80.16_ 80160 75 01080200-X
80 40 M12x25 25 150 200 D80.16_ 80200 76 01080250-X
80 40 M12x25 40 170 250 D80.16_ 80250 01080315-X
80 40 M12x25 40 235 315 D80.16_ 80315 01100100-X
100 50 M12x25 25 50 100 D80.16_100100 83 01100125-X
100 50 M12x25 25 75 125 D80.16_100125 84 01100160-X
100 50 M12x25 25 110 160 D80.16_100160 85 01100200-X
100 50 M12x25 25 150 200 D80.16_100200 86 01100250-X
100 50 M12x25 40 170 250 D80.16_100250 01100315-X
100 50 M12x25 40 235 315 D80.16_100315
80 30 M8x25 25 A 50 D80.16_ 80 50 71
100 50 M12x25 25 A 50 D80.16_100 50 81 01100050-X
100 50 M12x25 40 A 80 D80.16_100 80 82
125 75 M12x25 25 A 50 D80.16_125 50 91
125 75 M12x25 40 A 80 D80.16_125 80 92
125 37.5 37.5 M12x25 25 50 C 100 D80.16_125100 93 01125100-X
125 37.5 37.5 M12x25 25 75 C 125 D80.16_125125 94 01125125-X
125 37.5 37.5 M12x25 25 110 C 160 D80.16_125160 95 01125160-X
125 37.5 37.5 M12x25 25 150 C 200 D80.16_125200 96 01125200-X
125 37.5 37.5 M12x25 40 170 C 250 D80.16_125250 01125250-X
125 37.5 37.5 M12x25 40 235 C 315 D80.16_125315 01125315-X
160 110 M12x25 25 A 50 D80.16_160 50 101
160 110 M12x25 40 A 80 D80.16_160 80 102
160 55 55 M12x25 25 50 C 100 D80.16_160100 103 01160100-X
160 55 55 M12x25 25 75 C 125 D80.16_160125 104 01160125-X
160 55 55 M12x25 25 110 C 160 D80.16_160160 105 01160160-X
160 55 55 M12x25 25 150 C 200 D80.16_160200 106 01160200-X
160 110 M12x25 40 170 B 250 D80.16_160250
160 110 M12x25 40 235 B 315 D80.16_160315
160 55 55 M12x25 40 170 C 250 D80.16_160250.01 01160250-X
160 55 55 M12x25 40 235 C 315 D80.16_160315.01 01160315-X
