D82.01 Grafitli Sürtünme Plakası / Wear Plate With Graphite Insert

Malzeme - Material SAE 430B / Grafit
Sertlik - Hardness HB≥180
a I1 I2 I Cıvata / Bolt Sipariş Kodu | Order Code
18 15 45 75 2xM6 D82.01_18 75
18 25 50 100 2xM6 D82.01_18100
18 25 75 125 2xM6 D82.01_18125
18 25 100 150 2xM6 D82.01_18150
28 15 45 75 2xM6 D82.01_28 75
28 25 50 100 2xM6 D82.01_28100
28 25 75 125 2xM6 D82.01_28125
28 25 100 150 2xM6 D82.01_28150
38 15 45 75 2xM6 D82.01_38 75
38 25 50 100 2xM6 D82.01_38100
38 25 75 125 2xM6 D82.01_38125
38 25 100 150 2xM6 D82.01_38150
48 15 45 75 2xM6 D82.01_48 75
48 25 50 100 2xM6 D82.01_48100
48 25 75 125 2xM6 D82.01_48125
48 25 100 150 2xM6 D82.01_48150
