D82.02 Grafitli Sürtünme Plakası / Wear Plate With Graphite Insert
Malzeme - Material SAE 430B / Grafit
Sertlik - Hardness HB≥180
| a | b | I1 | I2 | I | Form | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|---|
| 28 | 15 | 45 | 75 | A | D82.02_028075 | |
| 28 | 25 | 50 | 100 | A | D82.02_028100 | |
| 28 | 25 | 75 | 125 | A | D82.02_028125 | |
| 28 | 25 | 100 | 150 | A | D82.02_028150 | |
| 38 | 15 | 45 | 75 | A | D82.02_038075 | |
| 38 | 25 | 50 | 100 | A | D82.02_038100 | |
| 38 | 25 | 75 | 125 | A | D82.02_038125 | |
| 38 | 25 | 100 | 150 | A | D82.02_038150 | |
| 48 | 15 | 45 | 75 | A | D82.02_048075 | |
| 48 | 25 | 50 | 100 | A | D82.02_048100 | |
| 48 | 25 | 75 | 125 | A | D82.02_048125 | |
| 48 | 25 | 100 | 150 | A | D82.02_048150 | |
| 48 | 50 | 100 | 200 | A | D82.02_048200 | |
| 58 | 15 | 45 | 75 | A | D82.02_058075 | |
| 58 | 25 | 50 | 100 | A | D82.02_058100 | |
| 58 | 25 | 75 | 125 | A | D82.02_058125 | |
| 58 | 25 | 100 | 150 | A | D82.02_058150 | |
| 58 | 50 | 100 | 200 | A | D82.02_058200 | |
| 75 | 15 | 45 | 75 | A | D82.02_075075 | |
| 75 | 25 | 50 | 100 | A | D82.02_075100 | |
| 75 | 25 | 75 | 125 | A | D82.02_075125 | |
| 75 | 25 | 100 | 150 | A | D82.02_075150 | |
| 75 | 25 | 75 | 200 | C | D82.02_075200 | |
| 100 | 50 | 25 | 50 | 100 | B | D82.02_100100 |
| 100 | 50 | 25 | 75 | 125 | B | D82.02_100125 |
| 100 | 50 | 25 | 100 | 150 | B | D82.02_100150 |
| 100 | 50 | 25 | 150 | 200 | B | D82.02_100200 |
| 100 | 50 | 25 | 200 | 250 | B | D82.02_100250 |
| 125 | 50 | 25 | 100 | 150 | B | D82.02_125150 |
| 125 | 50 | 25 | 150 | 200 | B | D82.02_125200 |
| 125 | 50 | 25 | 200 | 250 | B | D82.02_125250 |
| 150 | 100 | 25 | 100 | 150 | B | D82.02_150150 |
| 150 | 100 | 25 | 150 | 200 | B | D82.02_150200 |
