D85.02.02 Bronz Grafitli “V” Blok / “V” Driver, self-lubricating
Malzeme - Material SAE 430B / Grafit
Sertlik - Hardness HB≥180
| b | d1 | d2 | d3 | d4 | h1 | h3 | h4 | I1 | I2 | I3 | I4 | z | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 65 | 13.5 | 20 | 12 | 14 | 47 | 3 | 20 | 150 | 125 | 45 | - | 65 | D85.02.02_065150 |
| 65 | 13.5 | 20 | 12 | 14 | 47 | 3 | 20 | 200 | 175 | 95 | - | 65 | D85.02.02_065200 |
| 65 | 13.5 | 20 | 12 | 14 | 47 | 3 | 20 | 250 | 225 | 145 | 125 | 65 | D85.02.02_065250 |
| 65 | 13.5 | 20 | 12 | 14 | 47 | 3 | 20 | 300 | 275 | 195 | 150 | 65 | D85.02.02_065300 |
| 125 | 17.5 | 26 | 16 | 18 | 57 | 5 | 15 | 150 | 125 | 45 | - | 85 | D85.02.02_125150 |
| 125 | 17.5 | 26 | 16 | 18 | 57 | 5 | 15 | 200 | 175 | 95 | - | 85 | D85.02.02_125200 |
| 125 | 17.5 | 26 | 16 | 18 | 57 | 5 | 15 | 250 | 225 | 145 | 125 | 85 | D85.02.02_125250 |
| 125 | 17.5 | 26 | 16 | 18 | 57 | 5 | 15 | 300 | 275 | 195 | 150 | 85 | D85.02.02_125300 |
