D85.03.01 V Bronz Grafitli “V” Blok / “V” Driver, self-lubricating
Malzeme - Material SAE 430B / Grafit
Sertlik - Hardness HB≥180
| b | I1 | I2 | I3 | I4 | I5 | I6 | I7 | I8 | I9 | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|---|---|---|---|---|
| 65 | 100 | 20 | 80 | - | - | - | - | 40 | 20 | D85.03.01_3565100 |
| 65 | 150 | 25 | 75 | 125 | - | - | - | 50 | 50 | D85.03.01_3565150 |
| 65 | 200 | 25 | 75 | 125 | 175 | - | - | 50 | 100 | D85.03.01_3565200 |
| 65 | 250 | 25 | 75 | 125 | 175 | 225 | - | 50 | 150 | D85.03.01_3565250 |
| 65 | 300 | 25 | 75 | 125 | 175 | 225 | 275 | 50 | 200 | D85.03.01_3565300 |
