D85.03.02 “V“ Bloklar, Çelik / “V” Driver, Steel
Malzeme - Material CK45
Sertlik - Hardness 56 - 60 HRC
| b | I1 | I2 | I3 | I4 | I5 | I6 | I7 | I8 | I9 | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|---|---|---|---|---|
| 65 | 100 | 20 | 80 | - | - | - | - | 40 | 20 | D85.03.02_3565100 |
| 65 | 150 | 25 | 75 | 125 | - | - | - | 50 | 50 | D85.03.02_3565150 |
| 65 | 200 | 25 | 75 | 125 | 175 | - | - | 50 | 100 | D85.03.02_3565200 |
| 65 | 250 | 25 | 75 | 125 | 175 | 225 | - | 50 | 150 | D85.03.02_3565250 |
| 65 | 300 | 25 | 75 | 125 | 175 | 225 | 275 | 50 | 200 | D85.03.02_3565300 |
